LDB-56 Semi Automatic Top & Bottom Belts Driven Sealer

LDB-56

Application

Compact and durable design, easy to operate. Top and bottom belts driven suit for sealing high carton.

GET A FREE QUOTE

Main Function

This series is a single machine model, up and down “one” type automatic sealing, suitable for the same time period within the same specification carton.

Transmission design mode for the upper and lower belt drive, suitable for heavier cartons.

Applicable carton specifications, different specifications of carton manual adjustment.

Description

Carton size	150-∞(W)200-500(H)180-600mm
Table height	580(min.)~780mm(max.)
Working speed	700-1200ctns/hr
Machine size	(L)770(W)735(H)1200-1600mm
Power	110V/220V single phase, 50/60Hz or specified by client
Tape width	48mm,60mm,75mm(alternative use)
Machine net weight	95kgs
