LDE-50 Fully Automatic Side Belts Driven Sealer

LDE-50

Application

Fully automatic adjustment on height and width for various size carton. Side belts driven.

GET A FREE QUOTE

Main Function

This series is a single machine model, upper and lower “one” type automatic sealing, suitable for different specifications of cartons within the same time period.

The transmission design is driven by belts on both sides, suitable for lighter cartons.

Within the applicable carton specifications, the automatic start-up adjusts the height and width of different specifications of cartons, different sizes of cartons can be self-corrected and adjusted sealing.

Description

Carton size	(L)150-∞(W)150-500*(H)150-500mm
Table height	580(min.)~780mm(max.)
Working speed	300-750ctns/hr
Machine size	(L)1170(W)880(H)1150mm
Power	110V/220V single phase, 50/60Hz or specified by client
Pneumatic	5kg/cm²
Tape width	48mm,75mm(alternative use)
Machine net weight	180kgs
